SKU: PSBA106 12V Motorcycle Battery Load Tester Lead-acid Battery 100-2000 CCA Load Test Lithium Battery 10~1000 Multifunction Battery Analyzer Lead acid and Lithium Battery Tester Charging Start System Test Vehicle / Heavy Truck / Car / Ship / Motorcycle / SUV / yacht / scooter / Boat / Bike / cutter / Bicycle Battery Diagnosis General Factory Direct Selling
technical parameter
Auto Parts: Mr.Abbas
System voltage: 12V
Input voltage: 9V~15V
Working power supply: 9V~15V
Power supply requirements: No built-in battery is required
Capacity: Cold start Ampere (CCA), DIN, EN, IEC and battery ratings
Main control chip: APM32F103VCT6
Operating temperature: 0- + 50℃
Storage temperature: -20- + 70℃
LCD: 128x64
Test lead: 100cm / 40in
major function
1.Print data by PC via USB cable
2.Test cranking and charging (alternator) systems
3.Test 12V lead-acid and lithium batteries
4.Test battery voltage, CCA, internal resistance, health and charge
5.Analysis result: Good, Recharge, Charge Retest, Replace, Bad Cell & Replace
6.One-click quick function for real-time voltage test and same parameter batch batteries testing
7. Protection of short-circuit and reverse connection
8.Review latest test result
9. Support: German, English, French, Italian, Spanish, and Dutch
10. Product certification: CE FCC ROHS UKCA
measuring range
DIN/IEC: 20-1400
JIS: 26A17-245H52
CCA/BCI/CA/MCA/EN/SAE: 20-2000
GB: 30-220Ah
Product characteristics
Product application:
12V batteries for testing various 12V wet (liquid rich), valve-controlled lead or maintenance-free (MF), seal maintenance-free (SMF), absorption glass felt (AGM) and GEL, batteries (start [SLI], deep cycle and marine batteries). Lithium-ion battery, support the major battery standards JIS, SAE, EN, DIN and IEC.
test specification:
Lithium ion- -CCA / BCI / C A/MCA / EN / SEA-20-1000, DIN / IEC-20-700, and GB-2-120 Ah
Lead acid- -CCA / BCI / C A/MCA / EN / SEA-20-2000, DIN / IEC-20-1400, and GB-2-220 Ah
Starting[SLI],
Deep Cycled and Marine of Wet(Flood),
VRLA or Maintenance Free(MF),
Sealed Maintenance Free(SMF),
Absorption Glass Mat(AGM),
GEL battery,
EFB battery,
Lithium battery.
Support for battery standards:
CCA: Cold Cranking Amps, specified by SAE&BCI, most frequently used value for starting battery at 0F (-18C).
BCI: Battery Council International standard.
SAE: Society of Automotive Engineers Standard .
CA: Cranking Amps standard, effective starting current value at 0C.
MCA: Marine Cranking Amps , effective starting current value at 0C.
DIN: German Auto Industry Committee Standard.
IEC: Internal Electro technical Commission Standard.
JIS: Japan Industrial Standard, displayed on the battery as combination of the numbers and letters, e.g 55D23, 80D26.
EN: European Automobile Industry Association Standard .
GB: China National Standard.
Product size: 12x20x7.5cm
Package size: 13x21x8.5cm
Package weight: 300g
Quantity quantity: 40 pcs
